CPT Equipment
Taizhou Dixin Exploration Instrument Co., Ltd. is a leading enterprise of cone penetration testing equipment integrating R&D, manufacturing and sales. With its excellent product quality and high-quality on-site tracking service, the company has won the favor of users of geotechnical engineering survey units all over the country. At present, Dixin has become the largest manufacturer of crawler-type static sounding equipment in China and the largest manufacturer of crawler-type static sounding equipment in China. The CPT crawler equipment produced by the company has also successfully assisted important government projects at home and abroad for many times.
Why choose us?
Our certification
The company has passed the ISO900 international quality certification system. At present, the company has more than 30 patents, including 3 invention patents.
Our factory
The company has more than 16 Years Experience and has a modern production base with a construction area of more than 10,000 square meters.we have more than 40 Enterprise Employees.
Our equipment
It has advanced CNC machine tools and other high-precision processing equipment, high-precision testing equipment, etc., with more than 80 sets of equipment.
Professional services
The company has sent professional after-sales technicians to provide follow-up services for different survey fields in different regions for a long time, collected feedback information from on-site use.
Types of CPT Equipment
Cones
Cone technology has seen major developments over the past 20 years. The standard CPT cone now measures pore pressure and is referred to as a piezocone. The pore pressure element can also be mounted in one of three positions, depending on ground conditions and the purpose of the test. Over recent years, the importance of temperature effecting the electronics inside the cone has been recognised and this has led to better temperature compensation.
Rigs
CPT rigs come in all shapes and sizes depending on what is needed for each particular project. The larger the rig the more reaction weight it will have to push the cone in the ground. However, it is not always the case that you need a large rig to achieve the required depths in a certain ground condition. You also don’t always have the space for a large CPT rig so smaller ones may need be deployed instead.
Rigs are often divided into wheeled and tracked versions and these can come in different sizes. You can also get rigs that have both wheels and tracks on them, known as track-trucks. A good thing about the larger rigs is that they provide comfortable places for work not only for the CPT operator but also the supervising engineer.
Modular soil sampler
This device allows you to use your CPT push system to easily and reliably obtain soil samples.
Groundwater sampler
This device can be utilized to collect a discrete sample from an area of interest and allows the exploration to be grouted immediately after the sample is obtained, decreasing migration.
Grouting modules
These devices can be attached behind the cone to tremie grout the borehole upon retraction or can be used with a specialized cone that deposits a disposable tip at the end of a sounding and grouts the annular space created during retraction.
Conesipper
This module attaches behind a normal CPT cone to take liquid or gas samples as the cone is pushed into the ground. Samples can be obtained from multiple depths during a single sounding, saving time and money.
SMRT (soil moisture, resistivity and temperature) module
This multi-purpose module can provide long-term data for applications such as irrigation or monitoring landfill sites.
VTK Video Module
This module incorporates real-time video screening with LED hydrocarbon fluorescence detection.
Benefits of CPT Equipment
Continuous data
CPT provides continuous soil property data along the depth of the borehole, giving a detailed profile of soil behaviour.
01
Less disturbance
CPT causes less disturbance to the soil compared to SPT, making it suitable for sensitive environments or where undisturbed samples are required.
02
Automated data collection
CPT data collection is automated, reducing operator dependency and potential errors.
03
Variety of sensors
CPT can be equipped with various sensors, such as pore pressure sensors, allowing for the measurement of additional parameters.
04
Applications
Geotechnical
CPT provides information on the soil profile, which can be used to design foundations, provide quality control for ground improvement work or to check the condition of a levee or a dike, for example.
Hydrogeological
To analyse the level and flow of groundwater or the interaction between groundwater and the surrounding soil.
Geo-environmental
To check the length of unknown foundations or the presence of buried steel objects, but also to determine the presence of contaminants in the soil.
Technical Specification
|
Chassis |
Engineering hydraulic crawler chassis |
|
Chassis driving device |
Imported hydraulic travel motor (international general use) |
|
Track specifications |
Engineering rubber track or steel track |
|
Engine |
Four-cylinder engineering diesel engine (ECU electronic control, engine water temperature, oil pressure, Digital alarm and automatic shutdown protection function, digital display of accumulated working hours); water cooling |
|
Diesel tank capacity (L) |
49 |
|
Rated power-speed |
37KW-2300r/min |
|
Penetration device |
Double-piston hydraulic cylinder |
|
Stroke |
550mm or 1100 mm |
|
Rated penetration force |
100~250KN |
|
Rated pull-out force |
130~280KN |
|
Adjustable penetration test speed |
20 mm/s |
|
Card probe rod form |
Hydraulic clamp or pad plug-in dual-use |
|
Loading and unloading vehicle and leveling form |
4 long-stroke hydraulic outriggers; stroke 1500mm; dual-purpose loading and unloading vehicle leveling |
|
Anchoring form |
Double-acting force static detection equipment anchoring device |
|
Maximum dimensions |
3800×1800×2350 (length×width×height) mm |
|
Weight |
5T |
|
Hydraulic oil cooling form |
Air cooling |
|
Hydraulic oil tank capacity (L) |
170 |
|
Walking speed |
1~4 (km/h) |
|
Walking slope |
≤30 degrees |
|
The maximum allowable working environment temperature |
45C° |
|
Minimum ambient temperature |
–25 C° |
|
Ground anchor form |
Single-leaf or multi-leaf anchor |
|
Anchor diameter (mm) |
300~400 |
|
Matching probes |
10cm² or 15 cm² static probes for single and double bridges, electric cross-board probes, CPTU probes, multi-function digital probes, etc. (all European and international manufacturers can be matched) |
|
Measuring instrument |
Static detection data automatic acquisition instrument (all European and international manufacturers can be matched) |
|
Probe specification (mm) |
Integral high-strength jointless probe; Φ32~Φ42 (optional) |
