Economics CPT Crawler-Based

Features:

DYLZ crawler rig platform can be equipped with geotechnical engineering drilling rigs such as 100-type, 150-type, 200-type. It has top quality of full hydraulic engineering crawler chassis, which engine and hydraulic valve parts and other components are from famous enterprises both at domestic and abroad to ensure the stable and reliable performance of the equipment and timely after-sales service. Advanced hydraulic technology,using split-type combined multi-way reversing valve, has such good qualities,as compact structure, small size, convenient installation and maintenance, low pressure loss, good overload characteristics of overflow valve.Strong passability can carry out cone penetration operations in harsh environments such as beaches, river beaches, sand, snow, icy roads, paddy fields and muddy.

Main Technical Specification:

Chassis: Full hydraulic engineering crawler chassis

Chassis drive: imported original  hydraulic travel motor (international common use).

Chassis specification: Engineering rubber or steel Chassis.

Truck handling and horizontal form: 4 hydraulic legs, 1500mm stroke patent no.: 201220382939.5

Drill tower form: hydraulic lifting and folding

Engine: Single-cylinder 1115 electric start diesel engine horizontal four-stroke water-cooled

Rated power - speed: 16.2KW-2200r/min

Max transport profile size: 3400×1850×2300 (L×W×H）mm

Weight: 2.0 (exclude the rig)

Hydraulic tank capacity (L): 140

Speed: 1~4 (km/h); Walking slope: ≤30°

Working environment temperature: –25 C°-45C°
